Auxx-Lift
Easily store your items with the push of a button! Lift up to 600 lbs using steel aircraft cables. Made in the USA with SPAX® Fasteners. Built-in safety features – the only lift tested to UL standards. Installation available in Des Moines, West Des Moines, Ankeny, Altoona, Bondurant, Clive, Windsor Heights, Johnston, Waukee, Norwalk, Indianola,…
$1,429.00 – $2,349.00
Addons
-
Additional Hardware Kit
$199.00 -
Auxx-Cover
$180.00 -
Auxx-Guard
$348.00 -
Auxx-Hooks
$42.00 -
Extra high ceiling?
$100.00 -
Extra Remote Control
$30.00 -
Installation Services
$0.00
Description
We install locally, just select “Installations Services” from Addons and “Add to Cart” and get more info on installation pricing and scheduling for your lift. Fast turn around time.
Installation areas are primarily, Des Moines, West Des Moines, Ankeny, Altoona, Bondurant, Clive, Windsor Heights, Johnston, Waukee, Norwalk, Indianola, Pleasant Hill plus the state of Iowa overall. Installation is available in network for other states, feel free to call for more details.
General specs
- Model:Auxx-Lift 1400
- Lifting Capacity:Up to 400 lbs
- Max. Travel Distance:13′-6″ (18′-0″ w/ Extension)
- Min. stored height:8 in
- Speed:Avg. 30sec for 9′ ceilings
Ceiling Support
- Type:(2) 1 5/8″ x 60″ strut channel
- Fasteners:(8) 5/16″ x 4″ SPAX© Lag Bolts
- Mounting Area:5′ x 5′ over 3 joists/rafters
- Cable:1/8” Vinyl-coated Steel 7×19
- Cable Strength:2,000 lbs
Operating Requirements
- Switch Voltage:110V / 120V
- Transmitter:433.92 MHz
- Electrical Cord:10 FT / 16 gauge / NEMA 5-15
- Min. circuit size:15 amp (Standard household)
Platform Specs
- Thickness:2.5 inches
- Support Frame:C-Channels (15gauge)
- Face material:3 x 3 galv. Wire Mesh (4gauge)
Motors
- Type:IP44 (T-Motor)
- Rated Power:235 W
- Rated Current:2.2 A
- Voltage / Phase:100-120V AC / Single
- Tube Diameter:70mm (2-3/4 in)
- Motor speed:13 rpm
- Duty Cycle @ Max. Capacity:3 min on, 15 min off
Size and Weight
- Dimensions:3ft x 6ft, 3ft x 8ft, 4ft x 6ft, 4ft x 8ft
- Weight:128 lbs
Available Finishes
What’s in the box
- 2 Motors
- Controller
- Remote Control
- 2 C-Strut Channels
- Platform
- Mounting Hardware
Additional information
| Platform size. Choose your size. | 3×6, 3×8, 4×6, 4×8 |
|---|---|
| Motor. Choose lifting capacity. | 400 LBS, 600 LBS |
| Finish. Pick a color. | Silver Gray, Pearl White, Stainless Steel |
